HELP WITH FUZZY IMAGES ON PAINT SHOP X2

Post by MYSTICBLISS »

Hi really need some help before i go crazy. I have been making a header with text on and it looks amazing even really close up in the paint shop but when i save it and look at it again its really fuzzy. I have tried everything i can think of such as saving it as jpeg, tif etc and have tried every dpi setting i can think of and also tried to make it as a rastor & vector images etc. the header i am making has to be 850 x 150 in size for my website. heres an example of what happens:



really hope someone can help me...its prob something silly im doing wrong but am at a loss x x x
teknisyan
Posts: 2421
Joined: Wed Oct 06, 2010 4:18 pm
operating_system: Windows 7 Home Premium
System_Drive: C
32bit or 64bit: 64 Bit
motherboard: Sony Corporation VAIO
processor: Intel Corel i5
ram: 4 GB
Video Card: ATI Mobility Radeon HD 5650
sound_card: Realtek HD Audio
Hard_Drive_Capacity: 500 GB
Location: Riyadh, KSA
Contact:

Re: HELP WITH FUZZY IMAGES ON PAINT SHOP X2

Post by teknisyan »

Hello MYSTICBLISS,

When you try to save the file as JPEG, you may want to adjust the compression factor, the lower the factor the higher the quality of the image.

You can access this by clicking on the OPTION button when you click on FILE > SAVE AS... then OPTION button.
save as screen.jpg
save as screen.jpg (72.17 KiB) Viewed 2967 times
Save optoin.jpg
Save optoin.jpg (49.18 KiB) Viewed 2967 times
Like reading blogs?
About Tech
About Sports
Pnoy.Me - A URL Shortener
Follow me on Facebook & Twitter
wds937
Posts: 189
Joined: Mon Dec 13, 2010 8:58 pm
operating_system: Windows 7 Professional
System_Drive: C
32bit or 64bit: 32 Bit
motherboard: Dell 0HN7XN A01
processor: Intel Pentium Dual Core E5800 - 64-bit - 3.20 GHz
ram: 4 GB
Video Card: Intel G41 Express - integrated
sound_card: Realtek High Definition Audio - integrated
Hard_Drive_Capacity: 320 GB
Monitor/Display Make & Model: ASUS VS247
Location: New Orleans, LA, USA

Re: HELP WITH FUZZY IMAGES ON PAINT SHOP X2

Post by wds937 »

What will sometimes help, particularly in XI and X2:
1. Create your new image as 850 x 150 pixels, 72 pixels/inch
2. Flood fill your background color
3. Resize the image: uncheck Resample using, and set Resolution to 300 pixels/inch
4. Set the text tool to the desired font, size, colors, and stroke width (not too big on the stroke width); Anti-alias should be Sharp, and Create as should be Vector
5. Set your text onto the image, and position it as desired
6. Resize the image again: uncheck Resample using (should still be uncheked), and set Resolution back to 72 pixels/inch
7. Resize yet again: Resample using should be checked, and the Pixel dimensions should be 850 x 150 pixels
8. Save the image, merging down, as a .jpg (using minimum compression, as Abiel suggested)

Because you are not printing your image, the Resolution value, which deals with print size, should not make a difference. However, I have seen unpredicted interaction between resolution and text behavior. Temporarily changing the resolution to 300 pixels/inch will sometimes work around this. There is probably more to this, but I have bumped upon it by trial-and-error.
MYSTICBLISS
Posts: 2
Joined: Thu Mar 24, 2011 4:59 pm
operating_system: Vista Home Basic
System_Drive: C

Re: HELP WITH FUZZY IMAGES ON PAINT SHOP X2

Post by MYSTICBLISS »

thank you sooo much to the above two posts! will be trying it out and will let you know how i get on x x x
